Attributes

Productgroup ID	2
Section load in accumulation operation	700kg
Length min [L min]	6000mm
Length max [l max]	300mm
ESD	yes
Operating temperature [T] max	+40 °C
Weight	0kg
Delivery information	Fully assembled
Recommended accessories	Connection Kits,Section supports SZ 2/...,LU 2 Automatic Lubrication Unit
Material information	Section profile: Aluminum, natural; anodized,Glide profile: Polyamide or steel, corrosion-resistant,Glide profile: Polyamide or steel accumulation rollers,Small parts protection: Polyamide
Preferred values	160,240,320,400,480,640,800,1040,1200

• Conveyor medium: accumulation roller chain (suitable for use in an EPA)
• Reversible operation not permitted
• Motor mounting right or left
• Motor connection: optionally with cable/plug or terminal box motor connection
• Special models on request

BS 2/R-700 Belt Section
Special models on request, Motor connection: optionally with cable/plug or terminal box motor connection, Motor mounting right or left, Reversible operation not permitted, Conveyor medium: accumulation roller chain (suitable for use in an EPA)

• 3D CAD
• Data Sheet

LU 2 Automatic Lubrication Unit

LU 2 Automatic Lubrication Unit

Connection Kits

Connection Kits

Leg Sets

Leg Sets

Condition of Delivery

Fully assembled

BS 2/R-700 Belt Section

The belt section is a ready-for-operation conveyor section with its own drive for the transportation of workpiece pallets in the longitudinal direction, or for the transverse conveying of the workpiece pallet between parallel conveyor sections in conjunction with two HQ 2 lift transverse units.

Note: In the case of short, light workpiece pallets (lWT = 160, 240), it may be necessary to ensure that it is possible to run over conveyor trenches by installing the included acceleration element.

The following must be noted for this: Avoid accumulation above the acceleration element! Accumulation above the acceleration element causes severe roller wear and shortens the service life of the chain.



Energy efficiency – Rexroth 4EE

No.			3842998096
Max. section load in accumulation operation		kg	700
ESD			yes
Max. operating temperature	T	°C	+40
Material entry			Section profile: Aluminum, natural; anodized Slide profile: Polyamide or steel; corrosion-resistant Slide profile: Polyamide or steel accumulation rollers Small parts protection: Polyamide
Length	l	mm	300 ... 6000

Motor connection

Transport and nominal speed vN

Motor data
