GUSSET S 30X30

For subsequent installation in closed frame constructions, Bracket with thread for virtually gap-free mounting of surface elements, The surface element can be mounted in different positions: flush with the profile edge or in front of the profile (by break / Material Number:3842536490

GUSSET S 30X30

Material #3842536490

Request Quote

Attributes

Productgroup ID 2
Packaging unit 20
ESD yes
Dimensions 30x30
Material Diecast aluminum
Weight 0.02665kg
Scope of delivery Set incl. fastening material (FS)
Recommended accessories Variofix block S,Retainer ring
Required accessories Screw for fastening the surface element
Material information Bracket: Diecast aluminum,Fastening material: Steel, galvanized
Color Silver
Profile slot 8
  • Bracket with thread for virtually gap-free mounting of surface elements
  • For subsequent installation in closed frame constructions
  • The surface element can be mounted in different positions: flush with the profile edge or in front of the profile (by breaking off the centering lug)
Bracket S 30x30
For subsequent installation in closed frame constructions, Bracket with thread for virtually gap free mounting of surface elements, The surface element can be mounted in different positions: flush with the profile edge or in front of the profile (by break

Variofix Block

Variofix Block

For surface elements with a thickness of up to 13 mm For subsequent installation in closed frame constructions Asymmetrical form enables surface elements to be fastened in two different positions Clamping with snap-in clip or screw fitting with square nut M6 (included in scope of delivery) and screw Retainer ring for connecting the screw to the surface element (Machinery Directive 2006/42/EC)

CAD data

Retainer ring

Retainer ring

Secures the fastening screw to the surface element For use with all Variofix blocks, but not for the S bracket Retrofitting possible For various thread sizes

CAD data

FS1

FS2

FS3

Bracket S 20x20, 20x20 set

Bracket S 30x30 set 30x30

Bracket S 40/45, 40/45 set
